High Capacity Electronic Balances ESK-1T/2T/3T/5T
It comes with 5000 kg capacity and 20 g readability. The main benefits are: Highly Accurate Mass Determination, Minimized Weighing Errors, Secure Data Transfer and Highly Ergonomic Operation. Readability [d]: 5 g Maximum capacity [Max]: 1000kg
+86-18740041216 Consulting Consulting
Technical Parameter

Features:

Electromagnetic force transducer

Integrated below-hook weighing for under-balance applications

Removable stainless steel weighing pan

Backlit LCD display

Overload and underload alarms

Temperature compensation and timed calibration

Applications:

Weighing,Percent Weighing,Parts Counting,Check Weighing,Dynamic /Animal Weighing,

Filling,Totalization,Formulation,Differential Weighing,Density Determination

Construction:

Metal base, aluminium alloy top housing, stainless steel pan

Specifications:

Model

ES5000KX20

ES3000KX10

ES2000KX10

ES1000KX5

Max. (Capacity)

5000 kg

3000 kg

2000 kg

1000 kg

Readability(d)

20 g

10 g

10 g

5 g

Minimum Weight (U=1%, k=2), typical

200 g

100 g

100 g

50 g

Repeatability(±)

20 g

10 g

10 g

10 g

Linearity(±)

40 g

20 g

20 g

20 g

Sensitivity Drift

±2 ppm/℃

Make

LT

Calibration

Motorized External Calibration

Class

Class Ⅱ

Display

LCD

Response Time

3-5 Sec

Pan Size(mm)

1000 x 1200 mm or 1300 x 1800 mm

Tare Range

Full

Operating Temperature

+10℃ to +40℃

Density

Function Available

Unit

g,mg,oz,ct,lb,ozt,dwt

Application Mode

PCS/Percent Weighing,Animal Weighing,Density,Totalizing,(Add)Weighing

Baud Rate Options

1200,2400,4800,9600

Interface

RS232C

Power Supply

AC 220V/50-60 Hz

Dimension  (LxWxH)

1000×1200×300 mm

Gross Weight

260 kg

MOQ

1 Set

Customs Tariff Number

9027899090

Note:

The measuring range and model can be customized according to user requirements.

Density Determination Kit for Solid Samples(Optional)

Standard Accessories: Main Instrument,Weighing Pan,Ring,Power Adaptor,Antivibration Pad,Test Certificate



FAQs:

1.What are the main applications of laboratory balances?

Laboratory balances are widely used in research, industrial, pharmaceutical, food, and other sectors where precision and accuracy of mass measurements are crucial.

They are used to weigh chemical substances, samples, medications, laboratory materials, and other objects requiring precise mass measurement.

2.What are the differences between analytical and precision balances?

Analytical and precision balances are types of laboratory balances, but there are some differences between them.

Analytical balances are more precise and have a greater ability to accurately measure small masses, often to milligrams or even micrograms.

Precision balances usually have less precision and may have a higher capacity, but are still used for measurements requiring high accuracy.

3.How to care for a laboratory balance to ensure its accuracy?

To keep a laboratory balance in good condition and ensure its accuracy, it is important to regularly perform calibration according to the manufacturer’s recommendations.

It is also important to keep the balance clean and avoid exposure to environmental conditions that could affect its performance, such as vibrations, humidity, or temperature.

4.What factors should be considered when choosing a laboratory balance?

When choosing a laboratory balance, consider several factors such as the measurement range and precision, the type of samples that will be weighed, available features and calibration options, build quality, and compliance with standards and regulations related to laboratory measurements.

5.Are laboratory balances calibrated before delivery?

Most laboratory balances are calibrated before delivery by the manufacturer to ensure their accuracy.

However, regular calibrations in the laboratory are recommended according to the manufacturer’s guidelines to maintain high-quality measurements throughout the usage period.

6.What types of laboratory balances are available on the market?

Various types of laboratory balances are available on the market, including analytical, precision, and laboratory balances of different capacities and precision.

There are also specialized balances for specific applications, such as balances for weighing toxic substances, moisture analyzers, and others.

7.What are the advantages of using laboratory balances in a laboratory?

Laboratory balances allow for accurate and repeatable mass measurements, which are essential in many research and industrial fields.

They also provide standardization and precision in measurements, facilitating the conduct of experiments, scientific research, and quality control in production.
